Product Description

Overview & Basic Info
Model NO.JTD-QVS6050CNC
Type2D Video Measuring System
Operate MethodCNC
Load Bearing35kg
MaterialMarble
SoftwareQuickmeasuring
OriginChina
HS Code9031499090
Product Description
Double closed-loop motion control, embedded modules developed to control motor with precise positioning performance.
Surface light formed by 24 groups independent light source, each group are constant current source driver and 200-step continuous variable.
2D CNC Video Measuring Systems can measure point, line, circle, arc and oval, rectangular with multi-point positioning function.
Advanced data processing: Output measurement data to Word, Excel and AutoCAD directly for statistical analysis.
Product Parameters
Specification JTD-QVS3020CNC JTD-QVS4030CNC JTD-QVS5040CNC
Work Range (X*Y*Z) 300*200*200mm 400*300*200mm 500*400*200mm
Dimension 1540*866*1750mm 1540*1066*1750mm 1740*1116*1760mm
Resolution X/Y Axis ≤(3+L/200)um
CCD Optical System SONY color camera
Grating Ruler High precision ruler, resolution 0.5um
Packaging & Delivery
Package Size180*140*180cm
Gross Weight730.00kg
Delivery Time3-5 working days
Trade TermsFOB, CIF, EXW
Product Display
Vision Measurement System 1
Vision Measurement System 2
Vision Measurement System 3
Vision Measurement System 4
Vision Measurement System 5
Frequently Asked Questions
What is the measurement accuracy of the system?
The system provides high precision with X&Y axis resolution ≤(3+L/200)um and Z axis resolution ≤(4+L/200)um using 0.5um grating rulers.
What kind of software is used for the CNC measurements?
The machine utilizes Quickmeasuring software, which supports measuring points, lines, circles, arcs, and complex geometric intersections.
What are the available data export formats?
Measurement data can be exported directly to Word, Excel, and AutoCAD for further statistical and engineering analysis.
How is the machine protected during shipping?
We use professional export standard packaging, including poly bags and sturdy wooden cases to ensure the machine remains safe during transit.
What is the warranty period for this equipment?
We provide a 12-month warranty for the main boards and system components, along with life-long maintenance service.
What are the power requirements?
The standard power supply required is 220V±10%, 50Hz.
