Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
1 / 5
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine
Advanced Vision Measurement System with Automatic Calibration for CNC Machine

Advanced Vision Measurement System with Automatic Calibration for CNC Machine

Customization: Available
After-sales Service: Life-Long Maintenance Service
Warranty: 1 Year
Send Inquiry

Product Description

Basic Information Overview
Model NO.
JTD-QVS6050CNC
Type
2D Video Measuring System
Operate Method
CNC
Load Bearing
30kg
Material
Marble
Software
Quickmeasuring
Production Capacity
5000pieces/Year
HS Code
9031499090
Product Description
✔
Double closed-loop motion control, embedded modules developed to control motor with precise positioning performance.
✔
Surface light formed by 24 groups independent light source, each group are constant current source driver and 200-step continuous variable.
✔
2D CNC Video Measuring Systems can measure point, line, circle, arc and oval, rectangular with multi-point positioning and structure intersection functions.
✔
Advanced data processing functions: measurement data can be output to Word, Excel, and AutoCAD directly for statistical analysis.
Product Parameters
Specification JTD-QVS5040CNC JTD-QVS6050CNC
Work Range (X*Y*Z) 500*400*200mm 600*500*200mm
Dimension 1740*1116*1760mm 1740*1316*1760mm
X&Y-Axis Accuracy ≤(3+L/200)um
Z Axis Accuracy ≤(4+L/200)um
Resolution American GSI high precision ruler, 0.5um
Optical System SONY color camera / Auto Change Times Lens
Lighting LED Adjustable ring and surface light
Product Showcase
Vision Measurement System 1
Vision Measurement System 2
Vision Measurement System 3
Vision Measurement System 4
Vision Measurement System 5
Vision Measurement System 6
Packaging & Shipping
Trade Terms
FOB, CIF, EXW
Packing
Professional Export Wooden Case
Delivery Time
3-5 working days after deposit
Warranty
12 Months for main components
Frequently Asked Questions
Q: What is the measurement accuracy of this CNC system?
A: The X & Y-axis resolution is ≤(3+L/200)um, and the Z-axis is ≤(4+L/200)um, utilizing high-precision American GSI rulers.
Q: Which software does the machine use for data processing?
A: The system uses Quickmeasuring software, which supports direct data output to Excel, Word, and AutoCAD.
Q: What kind of lighting system is integrated?
A: It features a surface light formed by 24 independent groups of LED light sources with 200-step continuous variable control.
Q: Can this machine handle heavy workpieces?
A: Yes, the gantry type structure is designed with a marble base and can support a load weight of up to 30kg.
Q: What is the warranty and after-sales service policy?
A: We provide a 12-month warranty for the motherboard and machine, along with life-long maintenance services.
