📊 Basic Information
Application
Food, Fruit, Pet Food
⚙️ Equipment Characteristics & Functions
- Uniform refrigeration cold trap wall temperature with professional gas diversion technology.
- Equipped with internationally renowned compressor brands (Danfoss, Panasonic, Tecumseh, Embraco).
- Integrated quick freezing and drying—no need for extra ultra-low temperature refrigerators.
- 7-inch color LCD touch screen with human-computer interaction and mobile remote control options.
- Real-time display of cold trap temperature, vacuum degree, and running time.
- Automatic data saving with USB export support to prevent data loss.
- Multi-product formula storage for automated processing.
- Electric heating defrosting function included.
📋 Technical Specifications
| Model |
TC-FD04 |
TC-FD06 |
TC-FD10 |
TC-FD15 |
| Freeze Dried Area |
0.32-0.4 m² |
0.5-0.62 m² |
1.05 m² |
1.5 m² |
| Capacity |
4-6kg |
6-9kg |
10-15kg |
15-22kg |
| Tray Size (mm) |
200*400*20 |
250*500*20 |
270*650*20 |
270*798*20 |
| Max Ice Capacity |
5kg |
7kg |
12kg |
17kg |
| Power |
1320w |
1850w |
2420w |
3550w |
🖼️ Detailed Photos
🚀 Why Choose Our Technology
Our freeze-drying solutions are designed for professional food processing, offering high efficiency and stability. With a focus on technological innovation, we provide equipment that serves central kitchens, food plants, and large-scale catering operations. Our systems emphasize quality and user-friendly operation, ensuring maximum equipment utilization and cost savings.
❓ Frequently Asked Questions
What materials can be processed with this freeze dryer?
The equipment is suitable for various products including fruits, vegetables, meat, pet food, coffee liquid, herbs, and biological products.
Does the machine require a separate ultra-low temperature refrigerator?
No, this is an integrated quick-freezing and drying machine. The pre-freezing function is built-in, so no external refrigerator or liquid nitrogen is required.
Can I monitor the freeze-drying process remotely?
Yes, the system supports a mobile app remote monitoring function, allowing you to check parameters like temperature and vacuum degree from your phone.
Is the freeze-drying data saved automatically?
Yes, freeze-dried data is automatically saved to prevent loss. You can view, delete, or export this data via a USB connection.
What brands of compressors are used in the equipment?
We use internationally recognized brands such as Panasonic, Danfoss (SECOP), Tecumseh, and Embraco to ensure stable refrigeration performance.
What are the power requirements for the TC-FD04 model?
The TC-FD04 model operates on a 220V/50HZ power supply with a power consumption of 1320W.
